Cocoon Duct Occluder

The Cocoon Duct Occluder is used in the transcatheter closure of patent ductus arteriosus. It is a self expandable umbrella shaped device manufactured from braided nitinol wires and coated with platinum. Platinum provides superior biocompatible properties compared to Nitinol. The platinum coating also provides radio opacity which enables easy positioning in the defect. The discs are filled with polypropylene fabric which aids in total occlusion of defect.

Cocoon Duct Occluder - designed & developed by vascular innovations

Cocoon Duct Occluder
Accessory Set

Cocoon Duct Occluder Accessory set consists of
Delivery Sheath with hemostasis valve adapter - used to deliver the device.
Dilator – used to ease penetration of tissue
Loader – used to introduce the Cocoon Duct Occluder into the delivery sheath.
Delivery cable – The device is screwed onto the distal tip of the delivery cable, which allows for placement and retrieval of the device.

The delivery cable is packed separately from the other accessories. The 6 French (CDC6F) delivery cable can be used with Cocoon Septal and PFO occluders. A smaller delivery cable, 5 French is available for the Cocoon Duct occluders. This cable is normally used in infants. The Cocoon Duct Occluder Accessory set is available in 6F, 7F, 8F and 9F sizes.

Cocoon Duct Occluder Technical Specifications

Device Diameter at
Pulmonary Artery
Device Diameter at
Descending Aorta
Sheath size
COP0406 4 mm 6 mm 10 mm 7 mm 6-7 French
COP0608 6 mm 8 mm 12 mm 7 mm 6-7 French
COP0810 8 mm 10 mm 16 mm 8 mm 7-8- French
COP1012 10 mm 12 mm 18 mm 8 mm 7-8 French
COP1214 12 mm 14 mm 20 mm 8 mm 9-10 French
COP1416 14 mm 16 mm 22 mm 8 mm 9-10 French
COP1618 16 mm 18 mm 24 mm 8 mm 9-10 French
COP1820 18 mm 20 mm 26 mm 8 mm 9-10 French

To be updated shortly
